1# Create IP-VLAN L3 for docker environment.
 2docker network create \
 3    --driver ipvlan \
 4    --subnet=192.168.11.0/24 \
 5    --gateway=192.168.11.1 \
 6    -o parent=ens18 \
 7    -o ipvlan_mode=l3 \
 8    #-o ipvlan_flag=bridge \
 9    #-o com.docker.network.bridge.enable_icc=true \
10    #-o com.docker.network.bridge.enable_ip_masquerade=true \
11    rs_vlan
12
13# iptables config which will allow container access external network, because L3 no MAC address.
14sudo iptables -t nat -A POSTROUTING -s 192.168.11.0/24 -o ens18 -j MASQUERADE
15
16# Run container for testing.
17docker run --net=rs_vlan -it --rm busybox /bin/sh
18docker run --net=rs_vlan -it --rm --ip=172.88.1.128 busybox /bin/sh

 1# Create IP-VLAN L3 for docker environment (at home, no depend on OpenWrt which is inside of PVE).
 2docker network create \
 3    --driver ipvlan \
 4    --subnet=192.168.231.0/24 \
 5    --gateway=192.168.231.1 \
 6    -o parent=ens19 \
 7    -o ipvlan_mode=l3 \
 8    home_vlan
 9
10# iptables config which will allow container access external network, because L3 no MAC address.
11sudo iptables -t nat -A POSTROUTING -s 192.168.231.0/24 -o ens19 -j MASQUERADE
12
13# Run container for testing.
14docker run --net=home_vlan -it --rm --ip=192.168.231.111 busybox /bin/sh
15# ping test inside of busybox container
16ping 192.168.1.3
17ping 8.8.8.8
18
19# Connect exist container and home_vlan
20docker network connect home_vlan mysql-server --ip 192.168.231.5
21docker network connect home_vlan minio --ip 192.168.231.8

1# ref: https://docs.docker.com/engine/daemon/remote-access/
2sudo systemctl edit docker.service

1# Conmmon .ini style
2[Service]
3ExecStart=
4# ExecStart=/usr/bin/dockerd -H fd:// -H unix:///var/run/docker.sock -H tcp://172.88.0.11:2375 -H tcp://192.168.1.231
5# ExecStart=/usr/bin/dockerd --iptables=false --ipv6=false --ip6tables=false -H fd:// -H unix:///var/run/docker.sock -H tcp://172.88.0.11:2375 -H tcp://192.168.1.231
6ExecStart=/usr/bin/dockerd --ipv6=false --ip6tables=false -H fd:// -H unix:///var/run/docker.sock -H tcp://172.88.0.11:2375 -H tcp://192.168.1.231

 1# Create volume
 2docker volume create portainer_data
 3# Startup container
 4docker run -d \
 5           --name portainer \
 6           -v /var/run/docker.sock:/var/run/docker.sock \
 7           -v portainer_data:/data \
 8           portainer/portainer-ce:2.27.3
 9
10# Attach networks, IP: .254
11docker network connect rs_vlan portainer --ip 192.168.11.254
12docker network connect home_vlan portainer --ip 192.168.231.254

1# Provided share folder on the host machine at /opt/shared,
2# Each containers should attach this folder as a volume for data transfer or data backup,
3# For each containers will create sub folder of share folder which name will be container name,
4# And attach it on to /rocksolid/data inside of container.
5# Example for postgis
6-v /opt/shared/data/postgis:/rocksolid/data

 1# Create container
 2docker run -d \
 3           --name mysql \
 4           --env MYSQL_ROOT_PASSWORD="6yhn*IK<" \
 5           --env MYSQL_ROOT_HOST=% \
 6           -v /opt/shared/data/mysql:/rocksolid/data \
 7           mysql/mysql-server:8.0.15
 8
 9# Attach networks, IP: .5
10docker network connect rs_vlan mysql --ip 192.168.11.5
11docker network connect home_vlan mysql --ip 192.168.231.5

 1# Create container
 2docker run -d \
 3           --name postgis \
 4           -e POSTGRES_PASSWORD="6yhn*IK<" \
 5           -v /opt/shared/data/postgis:/rocksolid/data \
 6           postgis/postgis:16-3.5
 7
 8# Attach networks, IP: .6
 9docker network connect rs_vlan postgis --ip 192.168.11.6
10docker network connect home_vlan postgis --ip 192.168.231.6

1# Create container
2docker run -d \
3           --name redis \
4           -v /opt/shared/data/redis:/rocksolid/data \
5           redis/redis-stack:6.2.6-v9
6
7# Attach networks, IP: .7
8docker network connect rs_vlan redis --ip 192.168.11.7
9docker network connect home_vlan redis --ip 192.168.231.7

1docker run -d \
2           --name activemq \
3           -v /opt/shared/data/activemq:/rocksolid/data \
4           apache/activemq-classic:5.18.7
5
6# Attach networks, IP: .200
7docker network connect rs_vlan activemq --ip 192.168.11.200
8docker network connect home_vlan activemq --ip 192.168.231.200

 1docker run -d \
 2           --name minio \
 3           -e MINIO_ROOT_USER="root" \
 4           -e MINIO_ROOT_PASSWORD="6yhn*IK<" \
 5           -v /opt/shared/data/minio:/rocksolid/data \
 6           minio/minio:RELEASE.2025-04-03T14-56-28Z server /data --console-address ":80"
 7
 8# Attach networks, IP: .20
 9docker network connect rs_vlan minio --ip 192.168.11.20
10docker network connect home_vlan minio --ip 192.168.231.20

 1# Base micromamba image
 2FROM mambaorg/micromamba:2.0.8-cuda12.2.2-ubuntu22.04
 3
 4ARG ROCKSOLID_USER=rocksolid
 5ARG ROCKSOLID_UID=1000
 6ARG ROCKSOLID_GID=100
 7
 8USER root
 9
10RUN usermod "--login=${ROCKSOLID_USER}" "--home=/home/${ROCKSOLID_USER}" --move-home "-u ${ROCKSOLID_UID}" "${MAMBA_USER}" && \
11    groupmod "--new-name=${ROCKSOLID_USER}" --non-unique "-g ${ROCKSOLID_GID}" "${MAMBA_USER}" && \
12    # Update the expected value of MAMBA_USER for the
13    # _entrypoint.sh consistency check.
14    echo "${ROCKSOLID_USER}" > "/etc/arg_mamba_user" && \
15    :
16ENV MAMBA_USER=$ROCKSOLID_USER
17ENV USER=$ROCKSOLID_USER
18
19RUN apt-get update && apt-get upgrade -y && \
20    apt-get install -y --no-install-recommends sudo wget curl unzip git build-essential nano less ssh openssh-server net-tools iputils-ping && \
21    # We just install tzdata below but leave default time zone as UTC. This helps packages like Pandas to function correctly.
22    DEBIAN_FRONTEND=noninteractive apt-get install -y --no-install-recommends tzdata krb5-user libkrb5-dev libsasl2-dev libsasl2-modules && \
23    chmod g+w /etc/passwd && \
24    echo "ALL    ALL=(ALL)    NOPASSWD:    ALL" >> /etc/sudoers && \
25    touch /etc/krb5.conf.lock && chown ${ROCKSOLID_USER}:${MAMBA_USER} /etc/krb5.conf* && \
26    apt clean
27
28USER $MAMBA_USER
29
30WORKDIR "/home/${ROCKSOLID_USER}"
31
32COPY global-gitconfig /home/${ROCKSOLID_USER}/.gitconfig
33
34ENV SHELL=/bin/bash
35ENV EDITOR="nano"

1# Execute the command in the directory where the "Dockerfile-micromamba" file is located.
2docker build -t rocksolid/micromamba:2.0.8-cuda12.2.2-ubuntu22.04 -f ./Dockerfile-micromamba .

 1# Below container(s) also belong to the rs_vlan(Docker IP-VLAN Level 3);
 2# The volume "python" will be used to share storage data files between these containers;
 3# Example for Python 3.10 environment including jupyter-lab, which is service at port 80.
 4docker run -d \
 5           --name py310-micromamba \
 6           -v /opt/shared/data/python:/rocksolid/data \
 7           rocksolid/micromamba:2.0.8-cuda12.2.2-ubuntu22.04 /bin/bash -c "\
 8           micromamba install -y -n base -c conda-forge \
 9                      python=3.10 \
10                      jupyterlab \
11                      ipywidgets \
12                      jupyterlab-lsp \
13                      python-lsp-server && \
14           jupyter-lab --notebook-dir /home/rocksolid \
15                       --no-browser \
16                       --ip=0.0.0.0 \
17                       --port=80"
18
19# Attach networks, IP: .100
20docker network connect rs_vlan py310-micromamba --ip 192.168.11.100
21docker network connect home_vlan py310-micromamba --ip 192.168.231.100
22
23# Example for Python 3.12 environment including jupyter-lab, which is service at port 80.
24docker run -d \
25           --name py312-micromamba \
26           -v /opt/shared/data/python:/rocksolid/data \
27           rocksolid/micromamba:2.0.8-cuda12.2.2-ubuntu22.04 /bin/bash -c "\
28           micromamba install -y -n base -c conda-forge \
29                      python=3.12 \
30                      jupyterlab \
31                      ipywidgets \
32                      jupyterlab-lsp \
33                      python-lsp-server && \
34           jupyter-lab --notebook-dir /home/rocksolid \
35                       --no-browser \
36                       --ip=0.0.0.0 \
37                       --port=80"
38
39# Attach networks, IP: .101
40docker network connect rs_vlan py312-micromamba --ip 192.168.11.101
41docker network connect home_vlan py312-micromamba --ip 192.168.231.101

1docker run -d \
2           --name mlflow \
3           -v /opt/shared/data/mlflow:/rocksolid/data \
4           ghcr.io/mlflow/mlflow:v2.21.3 mlflow server --host 0.0.0.0 --port 80
5
6# Attach networks, IP: .253
7docker network connect rs_vlan mlflow --ip 192.168.11.253
8docker network connect home_vlan mlflow --ip 192.168.231.253
